Leírás
Szintén jól alkalmazható hasonló összetételű, stabilizált
anyagokhoz, kivétel ha az alapanyag teljes
kúszásállósága az elvárás. Az Elga Cromarod 316L-nek nagyon jók
az ívgyújtási és ívújragyújtási tulajdonságai, ami mellett
nagyon tetszetős varratfelszínt hoz létre. Salakja
önleváló. A bevonat LMA típusú (Low Moisture
Absorption) azaz alacsony nedvszívóképességű.
Packed Dimensions: Height 7.00cm x Width 7.00cm x Depth 31cm
Gross Weight: 3kg each
Cromarod 316L is a rutile flux coated AC/DC electrode intended for welding the low carbon, molybdenum alloyed, acid resisting austenitic stainless steels of similar composition (316L). Operability is excellent with a smooth low spatter arc producing an exceptionally good weld bead appearance. Fillet welds have a smooth surface, slightly concave profile with excellent toe line blend-in and a self-releasing slag. The electrode is all positional up to and including 3.25 mm diameter. Cromarod 316L is suitable for welding normal carbon 316 type grades and also Nb or Ti stabilised steels, provided service temperatures are below 400 °C. For 316 material grades used at elevated temperatures, Cromarod 318 is recommended.
Classification AWS A5.4: E316L-17
EN ISO 3581-A: E 19 12 3 L R 12
CSA W48 E316L-17
Werkstoffnummer 1.4430
Ferrite content:
FN 4 (WRC-92)
Corrosion resistance
Good resistance to general and intergranular
corrosion in the more severe environments e.g.
dilute hot acids. Good resistance to chloride pitting
corrosion.
Scaling temperature:
Approx. 850 °C in air.
Approvals:
CE
DNV
TÜV
Ismertető
anyagokhoz, kivétel ha az alapanyag teljes
kúszásállósága az elvárás. Az Elga Cromarod 316L-nek nagyon jók
az ívgyújtási és ívújragyújtási tulajdonságai, ami mellett
nagyon tetszetős varratfelszínt hoz létre. Salakja
önleváló. A bevonat LMA típusú (Low Moisture
Absorption) azaz alacsony nedvszívóképességű.
